MT Valves & Fittings product. Series 86 connector with connection for soldering to copper pipe and male thread. Brass body in accordance with standard UNE-EN 12164. Connector 86270, with thread locking in accordance with ISO 288/1, withstands a nominal pressure of 16 bar and an operating temperature of between -20 to 120°C. Thanks to its copper pipe soldering connection system, installation is quick and easy, saving time and making assembly more convenient. MT’s soldered brass fittings are manufactured in accordance with the hot stamping method and in accordance with EN 1254-1. They have high temperature and pressure resistance, making them ideal for both hot and cold water fluid handling applications and are suitable for EN 1057:2007 copper pipe systems. Available references and published specifications: • 862701215 — measures: F-CU STRAIGHT CONNECTOR 12X1/2"; weight (kg): 0.02; small / large box: 25 / 500 • 862701415 — measures: F-CU STRAIGHT CONNECTOR 14X 1/2"; weight (kg): 0.03; small / large box: 25 / 475 • 862701515 — measures: F-CU STRAIGHT CONNECTOR 15X1/2"; weight (kg): 0.02; small / large box: 25 / 350 • 862701520 — measures: F-CU STRAIGHT CONNECTOR 15X3/4"; weight (kg): 0.04; small / large box: 25 / 300 • 862701815 — measures: F-CU STRAIGHT CONNECTOR 18X1/2"; weight (kg): 0.03; small / large box: 25 / 375 • 862701820 — measures: F-CU STRAIGHT CONNECTOR 18X3/4"; weight (kg): 0.04; small / large box: 25 / 275 • 862702215 — measures: F-CU STRAIGHT CONNECTOR 22X1/2"; weight (kg): 0.03; small / large box: 25 / 300 • 862702220 — measures: F-CU STRAIGHT CONNECTOR 22X3/4"; weight (kg): 0.04; small / large box: 10 / 200 • 862702225 — measures: F-CU STRAIGHT CONNECTOR 22X1"; weight (kg): 0.07; small / large box: 10 / 150 • 862702820 — measures: F-CU STRAIGHT CONNECTOR 28X3/4"; weight (kg): 0.05; small / large box: 10 / 150 • 862702825 — measures: F-CU STRAIGHT CONNECTOR 28X1"; weight (kg): 0.07; small / large box: 10 / 110 Price and local availability on request. Source: https://mtspain.net/en/f-cu-connector/
